ADJ American DJ PIXIE-CURVE-60 1-Meter Curved LED Strip with Wired Digital Communication Network

ADJ American DJ PIXIE-CURVE-60 1-Meter Curved LED Strip with Wired Digital Communication Network

The Pixie Curve 60 is an indoor, 90-degree curved, LED pixel batten that adds another creative element to the current line-up of Pixie Series fixtures. It’s powered by sixty (60) tri-color RGB SMD LEDs with a 16.5mm pixel pitch, and is controlled and powered by a Pixie Driver unit.

Specifications:

• Source:
  • SMD RGB 3-in-1, APA-102C LEDs
  • Color Resolution: 8 bits per color (24 bit per pixel)
  • Viewing Angle: 120 x 120 degrees
  • Pixels Per Fixture: 60 pixels
  • Pixel Pitch (pixel center-to-center) 16.5mm
  • PWM (Pulse Width Modulation): 44,000Hz
  • 50,000 Hours Life
• Connectors:
  • 4-pin Power/Data Input & Output
• Dimensions & Weight:
  • Length: 25.72” (653.2mm)
  • Width: 1.36” (34.5mm)
  • Height: 3.11” (78.8mm)
  • Weight: 2.04 lbs. (1.2kg)
• Power:
  • DC24V
  • Max Power Consumption: 12W
• Thermal:
  • Ambient Operational Temperature: -4°F to 113°F (-20°C to 45°C)
  • Storage Temperature: -22°F to 113°F (-30°C to 45°C)
• Certifications & IP Rating:
• CE
• cETLus (Pending)
• FCC
• IP65
